Oriental 2020 Newest diode laser hair removal machine / 810nm diode laser hair removal

FOB Reference Price:Get Latest Price
$3,500.00 - $8,000.00 / Piece | 1 Piece/Pieces (Min. Order)
Color:
Blue Black Red GRAY
Lead Time:
Quantity(Pieces) 1 - 3 >3
Est. Time(days) 8 Negotiable
Customization:
Customized logo (Min. Order: 3 Pieces)
Customized packaging (Min. Order: 5 Pieces)

More

Graphic customization (Min. Order: 10 Pieces) Less
Samples:
$5,000.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Beijing, China
Brand Name:
oriental-laser
laser type:
Trio laser 808nm/755/1064nm
laser power:
800W=Power Consumption 2000W
Pulse width:
0-600ms
Energy density:
1-120J/cm
Frequency:
1-10HZ
Function:
Skin Rejuvenation
Operation mode:
HR-FHR-SR
Spot size:
15mm*25mm
Cooling type:
Sapphire contact cooling micro channle diode cooler
Water quality:
Deionized 2-10 us/cm,mixed bed ion exchanger,particle filter<25um
Product Certification certification
CE Certified.
Packaging & Delivery
Packaging Details
paper box package for Alma laser application laser stack replacement and update
Lead Time :
Quantity(Pieces) 1 - 3 >3
Est. Time(days) 8 To be negotiated
Video Description

Oriental 2020 Newest diode laser hair removal machine / 810nm diode laser hair removal



1.High Power Diode Laser Hair Removal Beauty Machine









2.Product Specifications

Product nameOriental-laser Newest diode laser hair removal machine /755 808 1064nm diode laser hair removal
Functionshair removal,fast hair removal,skin rejuvenation
Wavelength755nm + 808nm +1064nm mixed wavelength
Laser Diode Module800W,8bars*100W,micro channel,Germany 4.0 micro channel cooling laser bar
laser bar germanny power-exponent function laser bar
Continuous working hours7x24 hours Continuous working
Energy Density0~120J/cm2
Pulse Width0~600ms
Repetition Rate1~12Hz
Skin Cooling Temperature-5℃--5℃ by cooled Sapphire
Spot Size15mmx25mm
Interface LanguageAll Kinds,But no more than 2 languages per machine
LCD Screen10.4"
System Cooling MethodHitechi Freon Compressor Cooling+Air cooling+Water cooling+TEC
Input VAC220VAC / 50-60Hz or 110VAC / 50-60Hz
Warranty1 year or 10 million shots
Packing Box Dimension60(L)x57(W)x125(H)cm
Weight80KG

 If you want to increase the warranty, please contact me!

3.Laser Handpiece:755nm+808nm+1064nm

 The handpiece power of Oriental-laser defaults to 600W,popular in the market are 600w and 1200w.Of course, the power can be customized according to your needs.
The wavelength can be 755nm, 808nm or 1064nm optional or combined.






755nm Handpiece

755nm laser is allowing for even better energy absorption by the melanin chromophore. making it ideal for the widest range of hair types and color- especially light-colored and thin hair.
808nm Handpiece

810nm laser offers deep penetration of the hair follicle with high average power, a high repetition rate for fast treatment. The 808nm has a moderate melanin absorption level making it safe for darker skin types.
1064nm Handpiece

1064nm laser is allowing for moderate energy absorption by the melanin chromophore. making it a focused solution for darker skin types. At the same time, the 1064nm offers the deepest penetration of the hair follicle.
755 808 1064 ivyice755 808 1064 diode laser hair removal handpiece
Big Spot Size Handpiece

The light exit area is larger, and the treatment for hair removal in a large area is faster.
4.Micro Channel Cooling Diode Laser Stack(6bars &8bars& 10bars &12bars)-The heart of machine
Diode Laser consultation please click on the picture below

6 Bars Diode Laser Stack |
8 Bars Diode Laser Stack |
10 Bars Diode Laser Stack |
12 Bars Diode Laser Stack  |

* Jenoptik Laser Bars From Germany( Exclusive for top brands,Including (alma, syneron,oriental-laser) )
* Micro Channel Cooling Structure( The longest life laser cooling structure on the market )
* Gold tin hard solider technology(High temperature resistance, oxidation resistance)
* 7 Test Standards
* 755nm, 808nm, 1064nm and mixed wavelengths can be customized


5.Operating system interface
Independent research and development design interface, easy to operate, 3 treatment mode design, 4 different style interfaces to choose from.

6.Laser Hair Removal System Spare Parts
We offer customized service and spare parts assembly tutorials to provide customers with more flexible product solutions.
Spare Parts Products :Please click on the picture below



7.Cooling System —— a system that protects the heart
Water heat disspation system combine with the wind system
The process is water pump push the water flows circulation from water tank to handle,then
return to the water tank and lower the water temperature through the Freon compressor system

In Order To Get A Good Cooling Results
the water pump need higher pressure,we adopt centrifugal brushless water pump. Pressure stronger ,working stable . The water circulation speed faster.
We have configured the Japanese Freon compressor cooling system, which has more powerful cooling effect and faster cooling efficiency, which is 3-4 times the effect of the radiator.
It is the highest configuration and level on the market.
We adopt 4L water tank , combines these to get the best results , from the test feed back , our machine could working on max power for more then 12 hours without serious heat

8.Water filtering system
We have designed an impurity filtration system to ensure that the fine passage of the laser will not be blocked, ensuring a longer service life of the handpiece.
PP water filter : filter various particulate impurities in the liquid(rust, sand)
Ion-excahnge water filter : displacement of adsorbed ions
germicidal lamp devicesSterilization lamp : kill bacteria, fungi and microorganisms in water
Generally, germicidal lamp devices are rarely used in laser hair removal devices.

9.Control System
The control system is independently developed, with higher compatibility and stronger stability.
Multi-function system alarm system
In order to make the laser instrument safer and have a longer life, we have designed a professional standard safety alarm system from the water flow, temperature, operating system, etc., so that you can use it more safely in the hair removal process.
10.Main Machine And Accessories
Dedicated to laser beauty for 13 years, the manufacturer of laser hair removal systems, professional standard production process.


 11.Packing information
Professional standard packaging, safer delivery



 13.Factory Show
Oriental-Laser(Beijing)Co.,Ltd has a facility of 5,000 square feet of class 10k clean room & class 1000 local clean zone(according to federal standards 209E).Professionalism, focus, quality is our core goal,Oriental-laser(Beijing)Co.,Ltd is engaged in high power diode laser and diode pumped solid state laser module and system design for economic applications. Our products are now widely used in industry, medical,beauty, research and defense applications. Our solutions offer a competitive advantage in performance, reliability and efficiency.




14.FAQ
1. What is the laser power output per bar of 808nm diode laser?
100W/bar

2, Factory or distributor company?

Oriental-laser is really a factory, we have 500 square clean room.

3. Payment?

TT (Bank transfer), Western Union,paypal

4. What kinds of heat-sink you use in the 808nm diode laser handle piece?
We usually use Micro channel cooler heat-sink to build 808nm diode laser stack,which is with high reliability and long life-time.But if customer require,we can also provide macro-channel heat-sink diode laser stack with competitive price.
5.What is the delivery of time of 808nm diode laser machine?
Standard product of 808nm diode laser machine are all in stock.
Shipping via Express can be within 3-5 working days.While if customized, the machine can be shipped out within 2 weeks.
6. What is the warranty of 808nm diode laser machine?
For whole system,we give warranty of machine 1 year or 10 million shots of lifetime.
During this period,if any problem of machine,please feedback soon and we will solve your problem at our best and at the earliest time.

7. After-Sale service?

We supply product use training include the manual, DVD and online trainning .When a fault occurs, engineers and experts to provide guidance for the maintenance.

8. Safe?

Yes, the 808nm diode laser hair removal machine is safe for people. No deputy.

9,Cooling system?

We use Freon compressor which is imported from Germany.

10, how long for the treatment?

 Mostly two months, one treatment every two weeks.
